| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Failure Rate | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Power | |
| Output Voltage | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Cosel LDA50F-24-SNH is an enclosed AC/DC power supply converter designed for ITE (Commercial) applications. It features a single 24V output with a maximum current of 2.1A, delivering up to 50.4W of power.
The converter operates with a wide input voltage range of 85-264 VAC or 110-370 VDC, offering flexibility for various power sources. Its dimensions are 225.0mm in length, 65.0mm in width, and 36.0mm in height, with a chassis mount type.
Key specifications include an efficiency of 82%, an isolation voltage of 3kV, and an operating temperature range of -10°C to 60°C with derating. The unit is compliant with RoHS3 standards and meets the 60950-1 safety standard. It is also classified under MSL 1 Unlimited and REACH Unaffected.
This model is part of the LDA series and is suitable for applications requiring a reliable and versatile AC/DC power conversion solution.
The output voltage is 24V.
The output current is 2.1A.
The output power is 50.4W.
The input voltage range is 85 ~ 264 VAC or 110 ~ 370 VDC.
The operating temperature range is -10°C to 60°C (With Derating).
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level is 1 Unlimited.
