LDA300W-48-CT
Cosel
The Cosel LDA300W-48-CT is an open-frame AC/DC converter providing 48V output at 302.4W. It features universal input voltage and 86% efficiency.
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Failure Rate | |
| Features | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Power | |
| Package / Case | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage |
The Cosel LDA300W-48-C is a high-performance AC/DC converter designed for ITE (Commercial) applications. It provides a stable 48V output voltage with a maximum current of 6.3A, delivering up to 302.4W of power.
This open-frame converter operates with a wide input voltage range of 85-132 VAC and 170-264 VAC, offering universal input functionality. Key electrical features include adjustable output and an efficiency rating of 86%.
The unit is housed in a module package and designed for chassis mounting. It has dimensions of 255.0mm in length, 108.0mm in width, and 47.0mm in height. The operating temperature range is -10°C to 70°C with derating. It meets the 60950-1 standard and carries cCSAus, CE, cURus, and TUV approvals.
The output voltage is 48V.
The maximum output power is 302.4W.
The output current is 6.3A.
The isolation voltage is 3kV.
The operating temperature range is -10°C to 70°C (With Derating).
The dimensions are 255.0mm in length, 108.0mm in width, and 47.0mm in height.
The factory lead time is 6 weeks.
