| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Frequency | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Cosel LDA300W-24-C is an AC/DC power supply designed for commercial applications. This open-frame unit delivers a stable 24V output with a maximum power of 336W and an output current of 14A.
It operates with a wide input voltage range of 85-132 VAC and 170-264 VAC, supporting input frequencies from 47 Hz to 440 Hz. The converter boasts an efficiency of 86% and features like adjustable output and universal input. Its dimensions are 255.0mm L x 108.0mm W x 47.0mm H.
Designed for chassis mounting, the LDA300W-24-C is suitable for various industrial and ITE applications. It has an operating temperature range of -10°C to 70°C with derating and meets safety standards including cCSAus, CE, cURus, and TUV.
The output voltage is 24 V.
The maximum output power is 336 W.
The input voltage range is 85 ~ 132 VAC and 170 ~ 264 VAC.
The operating temperature range is -10°C to 70°C (With Derating).
The dimensions are 255.0mm L x 108.0mm W x 47.0mm H.
It uses chassis mount.
Yes, it is RoHS3 Compliant.
