| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Power | |
| Output Voltage | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Cosel LDA15F-12-M is an open-frame AC/DC power supply designed for ITE (Commercial) applications. It delivers a stable 12V output with a current capability of 1.3A, resulting in a total output power of 16W.
This converter operates with a wide input voltage range of 85-264 VAC or 110-370 VDC, offering flexibility for various power sources. It boasts an efficiency of 76% and features like adjustable output and universal input. The isolation voltage is rated at 3kV.
With dimensions of 125.0mm x 50.0mm x 21.0mm, the LDA15F-12-M is suitable for chassis mounting. It operates within a temperature range of -10°C to 60°C with derating. The unit is compliant with RoHS3 standards and is lead-free.
Key specifications include a single output, an isolation voltage of 3kV, and compliance with standard 60950-1. The approval agencies include cCSAus, CE, cURus, and TUV, indicating its suitability for various international markets.
The output voltage is 12V.
The output current is 1.3A.
The output power is 15.6W.
The input voltage range is 85-264 VAC or 110-370 VDC.
The operating temperature range is -10°C to 60°C (With Derating).
The dimensions are 125.0mm x 50.0mm x 21.0mm.
Yes, it is RoHS3 Compliant.
