| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Package / Case | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Cosel LDA15F-12-CY is an open-frame AC/DC converter designed for ITE (Commercial) applications. It delivers a stable 12V output with a current capability of 1.3A, resulting in a total output power of 16W.
This converter operates with a wide input voltage range of 85 to 264 VAC or 110 to 370 VDC, offering flexibility in power source selection. Key features include adjustable output and universal input, making it suitable for diverse system designs. The efficiency is rated at 76%.
With dimensions of 125.0mm in length, 50.0mm in width, and 21.0mm in height, the LDA15F-12-CY is designed for chassis mounting. It meets safety standards including cCSAus, CE, cURus, and TUV, and is compliant with RoHS3.
The operating temperature range is -10°C to 60°C with derating. The isolation voltage is 3kV, and it has a single output.
The input voltage range is 85 to 264 VAC or 110 to 370 VDC.
The package is a module with chassis mount mounting.
The operating temperature range is -10°C to 60°C with derating.
The output voltage is 12V.
The output current is 1.3A.
The power rating is 16W.
The isolation voltage is 3kV.
