The Cosel LDA150W-18-Y is an AC/DC open frame power supply designed for ITE (Commercial) applications. It operates with a universal input voltage range of 85-132 VAC and 170-264 VAC, providing a stable 18V output at a maximum current of 8.5A, for a total power output of 153W. The converter boasts an efficiency of 84% and features adjustable output and universal input capabilities.
With dimensions of 8.74" L x 2.95" W x 1.46" H (222.0mm x 75.0mm x 37.0mm), it is designed for chassis mounting. The operating temperature range is -10°C to 60°C with derating. This series is approved by cCSAus, CE, cURus, and TUV, adhering to standard 60950-1.
Key specifications include a single output, 153W power rating, and 8.5A maximum output current. The unit is built with an open frame construction suitable for integration into various systems requiring reliable power conversion.
The output voltage is 18V.
The maximum output current is 8.5A.
The power rating is 153W.
The input voltage range is 85 ~ 132 VAC and 170 ~ 264 VAC.
The operating temperature range is -10°C to 60°C (With Derating).
Key features include adjustable output and universal input.
It is approved by cCSAus, CE, cURus, and TUV.
