The Cosel LDA10F-5 is an AC/DC converter designed for commercial ITE applications. This unit delivers 10W of power with a stable 5V output and a maximum current of 2A. It features adjustable output capabilities and a universal input voltage range, accepting 85-264 VAC or 110-370 VDC.
The converter operates within a temperature range of -10°C to 60°C with derating. Its dimensions are 125.0mm x 57.0mm x 32.0mm, and it is designed for chassis mounting.
Key specifications include an efficiency of 72% and an isolation voltage of 3 kV. The LDA10F-5 complies with standard number 60950-1 and carries approvals from cCSAus, CE, cURus, and TUV.
Environmental compliance includes RoHS3 compliance and Moisture Sensitivity Level 1. This converter is a reliable choice for power supply needs in commercial electronic equipment.
85~264 VAC or 110~370 VDC.
Chassis Mount.
-10°C to 60°C with derating.
5V.
2A.
10W.
cCSAus, CE, cURus, TUV.
