The Multicomp Pro LD30-23B48R2 is an encapsulated DC DC converter with a maximum power rating of 30 Watts. It accepts a broad input voltage range of 85 to 305 Vac, making it suitable for various power applications.
The converter provides a stable 48 Vdc output voltage and can deliver a maximum current of 0.63 Amps. It operates efficiently with a low no-load power consumption of less than 0.1 Watt. The operating temperature range is from -40°C to +85°C, and it can function at altitudes up to 5000 meters.
Designed for PCB mounting, this converter offers a compact and integrated solution for power conversion needs. Its robust construction and wide operating parameters make it a reliable choice for industrial and commercial applications requiring a 48Vdc output.
Key specifications include an input voltage of 85-305 Vac, an output voltage of 48 Vdc, and a maximum output current of 0.63 A. The device has a maximum power of 30 W and an operating temperature range of -40°C to +85°C.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.06 | $2.06 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
85 to 305 Vac.
48 Vdc.
0.63 A.
30 W.
-40 to +85°C.
PCB mount, encapsulated.
Up to 5000 m.
