| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Length | |
| Mounting Type | |
| No Load Power Consumption | |
| Number of Outputs | |
| Operating Temperature | |
| Package / Case | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Mornsun LD20-23B12R2 is an enclosed AC/DC converter designed for board mounting. It provides a 12VDC output with a maximum current of 1.67A, delivering up to 20W of power. The converter accepts a wide input voltage range of 85-305VAC, making it suitable for various applications.
Key electrical specifications include an efficiency of 86% and a low no-load power consumption of less than 0.1 Watt. It operates reliably within an extended temperature range of -40°C to 85°C, with derating. The unit is designed for through-hole mounting and comes in a 6-DIP Module, 4 Leads package.
This AC/DC converter is suitable for applications in household appliances, ITE (Commercial), and medical equipment. It holds industrial safety certifications including IEC/EN 62368-1 and UL 62368-1. The product can operate at altitudes up to 5000m.
The input voltage range is 85 to 305 VAC.
The output is 12 VDC at 1.67 A.
The operating temperature range is -40°C to +85°C with derating.
The package is a 6-DIP Module with 4 leads, through-hole mounting.
The efficiency is 86%.
The no-load power consumption is less than or equal to 0.1 Watt.
The dimensions are 52.4 mm length, 27.2 mm width, and 24.0 mm height.
