| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Length | |
| Mounting Type | |
| No Load Power Consumption | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Package / Case | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Mornsun LD20-23B05R2 is an enclosed AC/DC power supply converter designed for various applications. It features a wide input voltage range of 85~305VAC and provides a stable 5VDC output with a maximum current of 4A, delivering up to 20W of power.
This converter operates efficiently at 85% and is built to withstand a broad temperature range from -40°C to 85°C, with derating applied. Its compact dimensions of 52.4mm x 27.2mm x 24.0mm and Through Hole mounting type make it suitable for PCB integration.
Key certifications include CB, CE, and cURus, indicating compliance with industrial safety standards. The device also boasts a low no-load power consumption of less than 0.1 Watt and can operate at altitudes up to 5000 meters. It is suitable for applications in household appliances, ITE (Commercial), and medical equipment.
85-305 VAC (100-430 VDC).
5 VDC.
4 A.
20 W.
85%.
-40°C to 85°C (with derating).
6-DIP Module, 4 Leads, through-hole mounting.
