| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Length | |
| Mounting Type | |
| No Load Power Consumption | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Mornsun LD15-23B24R2 is an enclosed AC/DC converter designed for board mounting. It provides a stable 24Vdc output at up to 625mA, delivering a total of 15W of power.
This converter features a wide input voltage range of 85-305Vac, making it suitable for various power applications. It boasts an efficiency of 86% and operates reliably within an extended temperature range of -40°C to 85°C, with derating. The unit is designed for through-hole mounting and comes in a 5-DIP module package with 4 leads.
Key specifications include a low no-load power consumption of less than 0.1 Watt and the ability to operate at altitudes up to 5000 meters. The LD15-23B24R2 is certified by CB, CE, and cURus, indicating compliance with industrial safety standards. Its applications include household appliances, ITE commercial equipment, and medical devices.
85~305Vac (100~430Vdc).
24Vdc at 0.625A.
15W.
-40°C to 85°C with derating.
5-DIP Module, 4 Leads, Through Hole mounting.
86%.
≤0.1W.
