The Morning Star Industrial LD15-23B12R2 is an AC/DC converter designed for board mount applications. It provides a stable 12Vdc output voltage with a maximum current of 1.25A, delivering a total power of 15W.
This converter features a wide input voltage range of 85-305Vac, making it suitable for various power environments. It operates efficiently at 85% and maintains functionality across an extended temperature range of -40°C to 85°C, with derating applied at higher temperatures. The unit is designed for through-hole mounting and comes in a 5-DIP module package with 4 leads.
Key specifications include a low no-load power consumption of less than 0.1 Watt and the ability to operate at altitudes up to 5000 meters. It is certified by CB, CE, and cURus approval agencies, indicating compliance with industrial safety standards. The dimensions are 47.6mm in length, 26.8mm in width, and 23.5mm in height.
The output voltage is 12Vdc.
The maximum output current is 1.25A.
The power rating is 15W.
The input voltage range is 85-305Vac.
The operating temperature range is -40°C to 85°C.
It is a 5-DIP Module with 4 leads.
