The Mornsun LD10-23B05R2 is an enclosed AC/DC converter designed for board mounting. It provides a stable 5VDC output at a maximum current of 2A, delivering up to 10W of power. The converter accepts a wide input voltage range of 85-305VAC, making it suitable for various power applications.
Key electrical specifications include an efficiency of 79% and a single output. The operating temperature range is -40°C to +85°C, with potential derating. Mechanically, it measures 40.0mm in length, 25.4mm in width, and 21.0mm in height, with a Through Hole mounting type.
This AC/DC converter is approved by CB, CE, and cURus, and complies with standards such as IEC/EN 62368-1. It is suitable for applications including household appliances and ITE (Commercial) equipment. The RoHS status is listed as RoHS3 Compliant, MSL is 1 Unlimited, and REACH status is Unaffected.
85-305 VAC.
5VDC at 2A.
10W.
-40°C to +85°C.
6-DIP Module, 4 Leads.
60335-1 and 62368-1.
CB, CE, cURus.
