The Mornsun LD05-23B03R2-M is a 4.95W AC/DC converter designed for reliable power conversion in various applications. It accepts an ultra-wide input voltage range of 85-305VAC and 100-430VDC, making it versatile for global use.
Key electrical specifications include a 3.3V output voltage at 1.5A, achieving an efficiency of 71.5%. The converter operates within an ambient temperature range of -40°C to +85°C, with derating applied. It offers essential protections such as short circuit and over-current protection.
This enclosed converter features a through-hole mounting type and a 4-DIP module package. It meets EMI standards like CISPR32/EN55032 Class B and is designed to meet safety standards including IEC/UL62368 and EN60335.
Applications for the LD05-23B03R2-M include household appliances and ITE (Commercial) equipment, where stable and efficient power conversion is critical. Its robust design and compliance with international standards ensure suitability for demanding environments.
85-305 VAC, 100-430 VDC.
3.3V at 1.5A, delivering 4.95W.
-40°C to 85°C with derating.
4-DIP Module, through-hole mounting.
Short circuit protection (hiccup, continuous, self-recovery) and over-current protection (≥120% Io).
71.5% typical.
