| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Country of Origin | |
| Current | |
| Depth | |
| Efficiency | |
| Failure Rate | |
| Features | |
| Height | |
| Length | |
| Maximum Input Voltage | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power | |
| Power (Watts) | |
| SVHC Present | |
| Standard Number | |
| Type | |
| Voltage | |
| Weight | |
| Width |
The XP Power LCW75US36 is an enclosed AC/DC power supply designed for industrial electronics, technology, and household applications. It provides a regulated 36V dc output with a maximum current of 2.1A, delivering up to 75W of power. The unit accepts a wide AC input range from 85V ac to 305V ac and features an efficiency of 89% (typical).
Key features include adjustable output voltage, output short circuit protection, over current protection, and over voltage protection. The operating temperature range is -30°C to 70°C. This power supply is designed for chassis mounting and meets standards such as EN 60335, EN 61558, EN 62368-1, and UL 62368-1.
Applications for the LCW75US36 include auxiliary power sources, security installations, lighting control, smart home or office control systems, and ticketing or vending applications. It is suitable for ITE (Commercial), Industrial, and Household Appliance use.
The XP Power LCW75US36 has a maximum output voltage of 36V dc.
The LCW75US36 has a power rating of 75W.
The operating temperature range for the LCW75US36 is -30°C to 70°C.
The LCW75US36 accepts an input voltage range of 85V ac to 305V ac.
The output current for the LCW75US36 is 2.1A.
The LCW75US36 complies with EN 60335, EN 61558, EN 62368-1, and UL 62368-1.
