The XP Power LCS50US12 is an enclosed AC/DC power supply from the LCS50 Series, delivering 50W of convection-cooled power. It provides a nominal output voltage of 12V with an adjustable range and a maximum current of 4.2A. The unit operates with an input voltage range of 85-264VAC and boasts a typical efficiency of 86% at full load.
Designed for versatility, the LCS50US12 is suitable for ITE, industrial, and household applications. It features short circuit, overvoltage, and overload protection, along with a 300VAC withstand voltage for 5 seconds. The dimensions are 99.0mm x 82.0mm x 30.0mm, and it is designed for chassis mounting.
Key electrical specifications include a maximum ripple and noise of 120mV pk-pk and a maximum capacitive load of 2000μF. The operating temperature range is -30°C to +70°C with derating. This power supply meets safety standards including 62368-1 and carries approvals from CE, TUV, and UL.
The nominal output voltage is 12VDC, with an adjustment range of ±10%.
The maximum output current is 4.2A.
The power rating is 50W.
The typical efficiency is 86% at 230VAC full load.
The operating temperature range is -30°C to +70°C with derating.
This AC/DC converter is designed for chassis mounting.
