LBA673 The ams-OSRAM LBA673-L2P1-35-Z4A4-10-R33-Z is a blue, clear surface mount LED. It features a 3.1V typical forward voltage and 35mcd luminous intensity.
Mfr Part #:

LBA673

Available from 1 distributors
Mfr Name: Osram
Osram
The ams-OSRAM LBA673-L2P1-35-Z4A4-10-R33-Z is a blue, clear surface mount LED. It features a 3.1V typical forward voltage and 35mcd luminous intensity.
✓ Total Stock: 51 pcs
$ Price Range: $1.20

LBA673 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
51 pcs
On Request
51 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

LBA673 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Failure Rate
Lens Color
Lens Size
Lens Style
Lens Transparency
Millicandela Rating
Mounting Type
Viewing Angle
View Similar Products (0)

LBA673 Description

Short technical summary and product information.

This ams-OSRAM LB A673-L2P1-35-Z4A4-10-R33-Z is a blue, clear surface mount LED designed for indication purposes. It operates with a typical forward voltage of 3.1V and a test current of 10mA, producing a luminous intensity of 35mcd.



The LED emits blue light with a dominant wavelength of 471nm and a peak wavelength of 466nm. It has a wide viewing angle of 120 degrees. The lens is colorless and clear, with a round, flat-top style and a diameter of 2.40mm.



Packaged in Cut Tape (CT) & Digi-Reel®, this component is designed for surface mounting with a right-angle orientation. The product status is listed as Obsolete.



Key electrical characteristics include a 3.1V typical forward voltage and 35mcd luminous intensity. The 120° viewing angle makes it suitable for various indicator applications where broad visibility is required.

LBA673 Quick Information

Product Type: LED Indication - Discrete
Series: SIDELED®
Canonical Name: ams-OSRAM LB A673-L2P1-35-Z4A4-10-R33-Z LED Blue Clear SMD R/A
Subcategory: Indication - Discrete

LBA673 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

LBA673 Estimated Pricing

Qty Low High
1+ $1.20 $1.20

Estimated market price range - modelled values for guidance only, not live distributor offers.

LBA673 Features

  • Blue clear SMD LED
  • 3.1V typical forward voltage
  • 35mcd luminous intensity
  • 120 degree viewing angle
  • Surface mount, right angle

LBA673 Applications

  • Status indicator for electronic devices
  • Backlighting for switches or panels
  • Visual signaling in automotive interiors
  • General purpose visual indication
  • Used in consumer electronics displays

LBA673 FAQs

6 frequently asked questions generated from this part’s specifications.
What is the typical forward voltage for the LBA673 LED?

The typical forward voltage is 3.1V.

What is the luminous intensity of the LBA673 LED?

The luminous intensity is 35mcd.

What is the viewing angle of the LBA673 LED?

The viewing angle is 120 degrees.

What is the dominant wavelength for this blue LED?

The dominant wavelength is 471nm.

How is the LBA673 LED packaged?

It is packaged in Cut Tape (CT) & Digi-Reel®.

What type of mounting does the LBA673 LED use?

It uses surface mount, right angle mounting.
