| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
937 pcs
|
937 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Forward Voltage | |
| Lead Spacing | |
| Lead Style | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Power Dissipation | |
| Reverse Current | |
| Reverse Voltage | |
| Viewing Angle | |
| Wavelength |
This Kingbright L-7113YD is a 5mm yellow diffused LED suitable for various electronic applications. It operates with a typical forward voltage of 2.1V and a forward current of 30mA, with a maximum forward current of 140mA. The LED has a typical luminous intensity of 20 mcd and a viewing angle of 30°, with a peak wavelength of 588 nm.
The component is constructed with AlGaInP material and is designed for through-hole (THT) mounting. It has a reverse voltage rating of 5V and a maximum reverse current of 10 µA. The operating temperature range is from -40°C to 85°C, with a power dissipation of 75 mW at 25°C.
Packaged in quantities of 1000 pieces, this LED is RoHS3 compliant and has an MSL rating of Level 1. Its specifications make it suitable for general lighting, indicator lights, and other optoelectronic applications where a yellow light source is required.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Kingbright L-7113YD LED is yellow.
The typical luminous intensity of the L-7113YD LED is 20 mcd.
The viewing angle of the Kingbright L-7113YD is 30°.
The wavelength of the L-7113YD LED is 588 nm.
The typical forward voltage for the L-7113YD LED is 2.1 V.
The operating temperature range for this LED is -40°C to 85°C.
The Kingbright L-7113YD LED is mounted using the through-hole (THT) method.
