| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Input Connector | |
| Input Frequency | |
| Input Type | |
| Input Voltage | |
| Mounting Type | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Power (Watts) | |
| Region Utilized | |
| SVHC Present | |
| Standard Number | |
| Storage Temperature | |
| Voltage |
The Tri-Mag, LLC L6R18-090 is a versatile 18W AC/DC wall mount power supply designed for ITE (Commercial) applications. It delivers a stable 9VDC output with a maximum current of 2.1A.
This adapter boasts a universal input voltage range of 90-264VAC and operates at frequencies between 47-63Hz. It meets the stringent DOE Level VI efficiency rating, ensuring reduced energy consumption. The unit features a NEMA 1-15P input connector and a standard barrel plug output (2.1mm I.D. x 5.5mm O.D. x 9.5mm) with a cord length of 59 inches (1.50m).
Designed for reliability, the L6R18-090 offers line regulation of ±1% and load regulation of ±5%. It operates within a temperature range of 0°C to 40°C and has a MTBF of 50,000 hours. Safety approvals include CE, cUL, and UL, adhering to standards like UL60950-1.
With its compact and lightweight wall-mount form factor, this power supply is suitable for various commercial and ITE equipment requiring a dependable 9V power source.
The output voltage is +9.0VDC.
The maximum output current is 2.1A.
The power rating is 18W.
Yes, it meets the DOE Level VI efficiency rating.
The operating temperature range is 0°C to 40°C.
It has a NEMA 1-15P input connector.
The dimensions are 71.1mm x 43.2mm x 33.0mm.
