L60030M1PQ The Littelfuse Inc. L60030M1PQ is a cartridge fuseholder rated for 600V and 30A. It features a chassis mount and screw terminal termination style.
Mfr Part #:

L60030M1PQ

Available from 1 distributors
Mfr Name: Littelfuse Inc.
Littelfuse Inc.
The Littelfuse Inc. L60030M1PQ is a cartridge fuseholder rated for 600V and 30A. It features a chassis mount and screw terminal termination style.
✓ Total Stock: 360 pcs
$ Price Range: $0.99

L60030M1PQ Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Smaxon Electronics ✓
Non-Authorised Inventory information
360 pcs
On Request
360 pcs On Request 1 On Request On Request 14+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

L60030M1PQ Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Contact Finish
Contact Material
Current Rating (Amps)
For Use With
Fuse Size
Fuse Type
Fuseholder Type
Mounting Type
Number of Circuits
Storage Temperature
Tape & Reel
Termination Style
Voltage
View Similar Products (0)

L60030M1PQ Description

Short technical summary and product information.

The Littelfuse Inc. L60030M1PQ is a cartridge fuseholder designed for robust circuit protection applications. It is rated for a maximum voltage of 600V and can handle a current of up to 30A.



This fuseholder features a chassis mount for secure installation and utilizes screw terminals with pressure plates for reliable connections, along with quick connect options. It is designed to accommodate cartridge fuses of size 5AG, 13/32" x 1-1/2" (Midget).



The fuseholder has one circuit and is constructed with a copper alloy contact material with a tin finish. Its dimensions are suitable for 0.394" Dia x 1.496" L (10mm x 38mm) fuses.

L60030M1PQ Quick Information

Product Type: Fuseholder
Canonical Name: Littelfuse Inc. L60030M1PQ Fuseholder
Subcategory: Cartridge Fuseholders

L60030M1PQ Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

L60030M1PQ Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

L60030M1PQ Features

  • Rated for 600V and 30A current.
  • Chassis mount for secure installation.
  • Screw terminal and quick connect options.
  • Accommodates 5AG, 13/32" x 1-1/2" fuses.
  • Single circuit fuseholder block.

L60030M1PQ Applications

  • Ideal for industrial control panels.
  • Suitable for power distribution units.
  • Used in equipment requiring fuse protection.
  • Designed for 5AG or Midget fuses.

L60030M1PQ FAQs

5 frequently asked questions generated from this part’s specifications.
What is the voltage rating of the L60030M1PQ fuseholder?

The L60030M1PQ fuseholder has a voltage rating of 600V.

What is the current rating for this fuseholder?

This fuseholder is rated for a current of 30A.

What type of fuse does the L60030M1PQ accept?

It accepts cartridge fuses of size 5AG, 13/32" x 1-1/2" (Midget).

How is the L60030M1PQ fuseholder mounted?

It is designed for chassis mounting.

What are the termination styles for this fuseholder?

The termination styles include screw terminal, pressure plate, and quick connect.
