L1C1-2280000000000 The Lumileds L1C1-2280000000000 is a warm white LED designed for various lighting applications. It operates at 350mA with a forward voltage of 2.75V.
Mfr Part #:

L1C1-2280000000000

Available from 1 distributors
Mfr Name: Lumileds
Lumileds
The Lumileds L1C1-2280000000000 is a warm white LED designed for various lighting applications. It operates at 350mA with a forward voltage of 2.75V.
✓ Total Stock: 1,000 pcs
$ Price Range: $0.99

L1C1-2280000000000 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Flip Electronics ✓
Non-Authorised Inventory information
1,000 pcs
On Request
1000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

L1C1-2280000000000 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
CCT (K)
CRI (Color Rendering Index)
Color
Current
Flux @ 85ﾂｰC, Current
Height
Length
Lumens
Mounting Type
Storage Temperature
Tape & Reel
Viewing Angle
Voltage
Width
View Similar Products (0)

L1C1-2280000000000 Description

Short technical summary and product information.

The Lumileds L1C1-2280000000000 is a warm white LED from the LUXEON C Color Line series. This component features a color temperature of 2200K and a Color Rendering Index (CRI) of 80, providing a warm and natural light.



Designed for surface mounting, this LED comes in a 3-SMD, No Lead package with dimensions of 2.00mm x 2.00mm and a height of 1.50mm. It operates with a typical forward voltage of 2.75V at a current of 350mA, delivering a luminous efficacy of 88 lm/W. The viewing angle is 150°.



This LED is suitable for applications requiring specific color temperatures and good color rendering, such as architectural lighting, entertainment, and high-impact retail displays. Its compact size and surface-mount capability facilitate integration into various lighting designs.

L1C1-2280000000000 Quick Information

Product Type: LED
Canonical Name: Lumileds L1C1-2280000000000 Warm White LED
Subcategory: Color LEDs

L1C1-2280000000000 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

L1C1-2280000000000 Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

L1C1-2280000000000 Features

  • Warm white LED with 2200K CCT.
  • High CRI of 80 for accurate color rendering.
  • Surface mount 3-SMD, No Lead package.
  • Compact dimensions: 2.00mm x 2.00mm x 1.50mm.
  • Operates at 350mA with 2.75V forward voltage.

L1C1-2280000000000 Applications

  • Ideal for warm white illumination needs.
  • Suitable for architectural lighting designs.
  • Used in high-impact retail displays.
  • Applicable in entertainment lighting setups.

L1C1-2280000000000 FAQs

5 frequently asked questions generated from this part’s specifications.
What is the color temperature of this LED?

The color temperature of this LED is 2200K.

What is the Color Rendering Index (CRI) for this LED?

The CRI for this LED is 80.

What is the typical forward voltage for this LED?

The typical forward voltage for this LED is 2.75V at 350mA.

What is the package type for this LED?

This LED is supplied in a 3-SMD, No Lead package.

How is this LED mounted?

This LED is designed for surface mounting.
