| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
59 pcs
|
59 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Frequency | |
| Height | |
| Inductance | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Shielding | |
| Storage Temperature | |
| Supplier Device Package | |
| Tape & Reel | |
| Tolerance | |
| Type | |
| Width |
The Yageo L1210R100MDWIT is a fixed inductor designed for surface mount applications. It offers an inductance value of 10 µH with a tolerance of ±20% and a DC resistance of 133 mOhm.
This wirewound, drum core inductor operates at a frequency of 23 MHz and can handle a current rating of 900 mA. The operating temperature range is -40°C to 105°C. The component is housed in a 1210 (3225 Metric) package, measuring 3.20mm in length, 2.50mm in width, and 2.70mm in height.
It is constructed with a ferrite material and is unshielded. The RoHS status is RoHS3 Compliant, and the Moisture Sensitivity Level (MSL) is 1 Unlimited.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.20 | $0.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance is 10 µH.
The current rating is 900 mA.
The DC resistance is 133 mOhm.
The operating temperature range is -40°C to 105°C.
It is a wirewound, drum core inductor.
The package size is 1210 (3225 Metric).
