| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
30 pcs
|
30 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Capacitance | |
| Color | |
| Forward Voltage | |
| Material | |
| Mounting Type | |
| Power Dissipation | |
| Reverse Voltage | |
| SVHC Present | |
| Viewing Angle | |
| Wavelength |
This Kingbright L-113GDT is a green rectangular LED with a diffused lens, suitable for various indication applications. It operates with a typical forward voltage of 2.25V and a forward current of 25mA, with a maximum allowable forward current of 140mA. The LED has a luminous intensity of 5 mcd and a wide 110° viewing angle, making it ideal for general-purpose indicator lights.
The component is constructed with GaP material and is designed for through-hole mounting (THT). It has a rated reverse voltage of 5V and can operate within a temperature range of -40°C to 85°C. The package quantity is 1000 pieces.
Key electrical characteristics include a wavelength of 568 nm, a capacitance of 15 pF, and a power dissipation of 105 mW at 25°C. The RoHS status is RoHS3 Compliant, and the Moisture Sensitivity Level (MSL) is 1.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.07 | $0.07 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The typical luminous intensity is 5 mcd.
The viewing angle is 110°.
The typical wavelength is 568 nm.
The typical forward voltage is 2.25 V.
Typical forward current is 25 mA; maximum forward current is 140 mA.
-40°C to +85°C.
2mm x 5mm rectangular through-hole package.
