| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
13 pcs
|
13 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Beam Angle | |
| Capacitance | |
| Color | |
| Forward Voltage | |
| Halogen Free | |
| Industrial Grade | |
| Lead Style | |
| Material | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Operating Temperature | |
| Power Dissipation | |
| Reverse Current | |
| Reverse Voltage | |
| SVHC Present | |
| Wavelength |
The Kingbright L-7104SURDK is a 3mm LED with a hyper red color and a diffused lens. It is constructed from AlGaInP material and operates with a typical forward voltage of 1.95V and a maximum forward current of 30mA. The luminous intensity is rated at 900 mcd with a beam angle of 50 degrees.
This LED has a reverse voltage rating of 5V and a reverse current of 10µA. Its power dissipation is 75mW at 25°C. The operating temperature range is from -40°C to 85°C. The component is mounted using the Through-Hole Technology (THT) method and comes in a standard package of 500 pieces.
The L-7104SURDK is RoHS3 compliant and has an MSL rating of 1. It is suitable for applications requiring a reliable red light source with specific optical characteristics.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The LED is hyper red with a red diffused lens.
The typical luminous intensity is 900 mcd.
The beam angle is 50 degrees.
The typical forward voltage is 1.95 V.
The maximum forward current is 30 mA.
The operating temperature range is -40°C to 85°C.
It is mounted using the THT (Through-Hole Technology) method.
