L-115WGYW The Kingbright L-115WGYW is a 3mm white diffused LED that emits green/yellow light. It features a 60° beam angle and is suitable for THT mounting.
Mfr Part #:

L-115WGYW

Available from 1 distributors
Mfr Name: Kingbright
Kingbright
The Kingbright L-115WGYW is a 3mm white diffused LED that emits green/yellow light. It features a 60° beam angle and is suitable for THT mounting.
✓ Total Stock: 3,342 pcs
$ Price Range: $0.99

L-115WGYW Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
3,342 pcs
On Request
3342 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

L-115WGYW Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Beam Angle
Color
Lead Spacing
Lead Style
Material
Mounting Type
Operating Temperature
Reverse Current
Reverse Voltage
SVHC Present
View Similar Products (0)

L-115WGYW Description

Short technical summary and product information.

The Kingbright L-115WGYW is a 3mm, 3-pin, through-hole (THT) mounted LED with a white diffused lens, emitting green/yellow light. It offers a typical luminous intensity of 40 mcd for green and 20 mcd for yellow, with a wide 60° beam angle. The LED operates with a forward voltage of 2.2V (green) / 2.1V (yellow) and a typical forward current of 25mA (green) / 30mA (yellow). It has a maximum reverse voltage of 5V and a maximum forward current of 140mA. The operating temperature range is from -40°C to 85°C. The material composition is GaP / GaAsP/GaP. This LED is packaged in a 500-piece bag.



This component is designed for general indication purposes where a diffused light source is required. Its THT mounting makes it suitable for traditional PCB assembly processes. The green/yellow dual-color output can be utilized in applications requiring status indication or simple signaling.



Key electrical characteristics include a maximum power dissipation of 62.5mW at 25°C, a maximum reverse current of 10uA, and capacitance values of 15pF and 20pF. The ESD threshold is rated at 8000V, providing some protection against electrostatic discharge during handling.

L-115WGYW Quick Information

Product Type: LED
Series: L-115
Canonical Name: Kingbright L-115WGYW 3mm White Diffused Green/Yellow 3-Pin THT LED
Subcategory: Discrete LEDs

L-115WGYW Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

L-115WGYW Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

L-115WGYW Features

  • 3mm white diffused green/yellow LED.
  • 60° wide beam angle.
  • Through-hole (THT) mounting.
  • Operating temperature -40 to 85°C.
  • Packaged in 500-piece bags.

L-115WGYW Applications

  • Ideal for status indication.
  • Suitable for general signaling.
  • Used in THT PCB assemblies.
  • Provides diffused light output.

L-115WGYW FAQs

7 frequently asked questions generated from this part’s specifications.
What is the color of the light emitted by the L-115WGYW LED?

The L-115WGYW LED emits green/yellow light.

What is the typical luminous intensity of the L-115WGYW LED?

The typical luminous intensity is 40 mcd for green and 20 mcd for yellow.

What is the beam angle of the L-115WGYW LED?

The beam angle is 60 degrees.

What is the forward voltage for the L-115WGYW LED?

The typical forward voltage is 2.2V for green and 2.1V for yellow.

What is the maximum reverse voltage for this LED?

The maximum reverse voltage is 5V.

What is the operating temperature range for the L-115WGYW LED?

The operating temperature range is -40°C to 85°C.

How is the L-115WGYW LED mounted?

The L-115WGYW LED is mounted using the THT (Through-Hole Technology) method.
