| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
81 pcs
|
81 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Composition | |
| Features | |
| Height | |
| Length | |
| Number of Terminations | |
| Operating Temperature | |
| Operating Temperature Range | |
| Power (Watts) | |
| Power Rating | |
| Rated Voltage | |
| Ratings | |
| Resistance | |
| Storage Temperature | |
| Supplier Device Package | |
| Tape & Reel | |
| Temperature Coefficient | |
| Tolerance | |
| Width |
This ROHM Semiconductor KTR10EZPF2004 is a surface mount chip resistor designed for high voltage applications. It features a resistance of 2 MΩ with a tight tolerance of ±1% and a power rating of 0.125W (1/8W). The operating temperature range is -55°C to 155°C, making it suitable for demanding environments.
The resistor is housed in a standard 0805 (2012 Metric) package with dimensions of 2.00mm L x 1.25mm W x 0.65mm H. Its thick film composition and high voltage capabilities, along with AEC-Q200 automotive qualification, make it ideal for use in automotive circuits and other high-reliability applications. The component is supplied on tape and reel for automated assembly processes.
Key electrical characteristics include a temperature coefficient of ±100ppm/°C. The KTR series resistors are designed to offer twice the rated voltage of conventional products, further enhancing their suitability for high voltage circuits.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.05 | $0.05 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The resistance value is 2 MΩ.
The tolerance is ±1%.
The power rating is 0.125W, or 1/8W.
The operating temperature range is -55°C to 155°C.
It is available in the 0805 (2012 Metric) package size.
Yes, it is AEC-Q200 qualified.
The temperature coefficient is ±100ppm/°C.
