KSZ8382L The Microchip Technology KSZ8382L is a telecom interface IC designed for IP-based communication. It features an LCD interface and is available in a Surface Mount package.
Mfr Part #:

KSZ8382L

Available from 1 distributors
Mfr Name: Microchip Technology
Microchip Technology
The Microchip Technology KSZ8382L is a telecom interface IC designed for IP-based communication. It features an LCD interface and is available in a Surface Mount package.
✓ Total Stock: 25,984 pcs

KSZ8382L Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Smaxon Electronics ✓
Non-Authorised Inventory information
25,984 pcs
On Request
25984 pcs On Request 1 On Request On Request 2020+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

KSZ8382L Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Function
Interface
Mounting Type
Number of Circuits
Operating Temperature
Supplier Device Package
View Similar Products (0)

KSZ8382L Description

Short technical summary and product information.

The KSZ8382L from Microchip Technology is a highly integrated System-on-Chip (SoC) designed to provide a complete solution for IP-based communication applications. This telecom interface IC is part of the KSZ8382 SoC family, known for its robustness and proven reliability in commercial, industrial, and automotive environments.



The device architecture includes a multiprocessor system with an embedded RISC CPU and DSP, enabling flexible VoIP platforms with high-quality voice processing. It features extensive integration, including a high-performance audio subsystem, an LCD interface, a keypad scanner, and memory controllers for SDRAM and DDR2. The KSZ8382L also incorporates a low-power 10/100 Ethernet switch with support for IEEE 802.1p QoS and 802.1Q VLANs.



Designed for cost-effectiveness and energy efficiency, the KSZ8382L reduces the need for external components and lowers operational costs. Its advanced power management includes energy-efficient Ethernet (EEE), making it compliant with EU Ecodesign regulations for low standby power. The integrated 3-port switch allows for additional IP device connections, and built-in IGMP snooping supports multicast systems.



This IC is suitable for developing a wide range of IP-based communication solutions such as IP phones, emergency systems, intercoms, and kiosks. It is supplied in a 176-LQFP package and is designed for Surface Mount applications, operating within a temperature range of 0°C to 70°C.

KSZ8382L Quick Information

Product Type: Telecom IC
Canonical Name: KSZ8382L Telecom Interface IC
Subcategory: Telecom

KSZ8382L Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

KSZ8382L Features

  • Highly integrated SoC for IP-based communication.
  • Features LCD interface and multiprocessor architecture.
  • Includes low-power 10/100 Ethernet switch.
  • Operates from 0°C to 70°C.
  • Surface Mount 176-LQFP package.

KSZ8382L Applications

  • Ideal for IP phones and emergency systems.
  • Suitable for intercom and paging systems.
  • Enables kiosk and vending machine solutions.
  • Supports cloud-based communication services.

KSZ8382L FAQs

3 frequently asked questions generated from this part’s specifications.
What is the operating temperature range for the KSZ8382L?

The operating temperature range for the KSZ8382L is 0°C to 70°C.

What package type is the KSZ8382L supplied in?

The KSZ8382L is supplied in a 176-LQFP package.

What is the mounting type for the KSZ8382L?

The KSZ8382L is designed for Surface Mount.
