| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,205 pcs
|
1205 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Beam Angle | |
| Lens Type | |
| Material | |
| Mounting Type | |
| Power Dissipation | |
| Reverse Current | |
| Reverse Voltage |
This Kingbright KPBD-3224SYKCGKC is a surface-mount device (SMD) LED designed for applications requiring dual-color illumination. It emits both yellow and green light, with typical luminous intensities of 800mcd and 280mcd respectively at 30mA forward current. The LED has a water-clear lens and a compact 3.2 x 2.4 x 2.4 mm package, making it suitable for space-constrained designs.
The operating voltage is typically 2V for yellow and 2.1V for green, with a maximum forward current of 30mA. The component operates within a temperature range of -40°C to 85°C and has an ESD threshold of 3000V. Its wavelength is 590nm for yellow and 570nm for green, with a typical beam angle of 20°.
Designed for surface mounting, this LED is supplied in a 1500-piece reel. Its RoHS3 compliant status and MSL 1 rating indicate suitability for various manufacturing processes.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
This LED emits both yellow and green light.
The typical forward voltage is 2V for yellow and 2.1V for green.
The maximum forward current is 30mA.
The typical luminous intensity is 800mcd for yellow and 280mcd for green.
The operating temperature range is -40°C to 85°C.
The dimensions are 3.2 x 2.4 x 2.4 mm.
The standard package quantity is 1500 pieces.
