The TDK Corporation KMT40-51212 is an enclosed AC/DC converter with a power rating of 40W. It is designed for through-hole mounting and features universal input capabilities.
This converter provides an output voltage of -12V and supports multiple output currents including 5A, 600mA, and 600mA. It is suitable for medical applications and meets standards such as 60601-1, 60950-1, and 62368-1. The operating temperature range is -25°C to 70°C with derating.
Key specifications include an efficiency of 80% and dimensions of 89.0mm x 63.5mm x 27.0mm. The unit is approved by CE, EN, IEC, and UL.
Compliance information indicates RoHS3 compliance, MSL 1, and REACH unaffected status. The package type is a 7-DIP module.
The converter provides three outputs: 5V, +12V, and -12V.
40W.
80%.
-25°C to 70°C with derating.
7-DIP Module.
Through Hole.
CE, EN, IEC, UL, and complies with standards 60601-1, 60950-1, 62368-1.
