The TDK Corporation KMD15-55 is an enclosed AC/DC converter designed for various applications, including medical use. It delivers 15W of power with a single -5V output voltage and a current rating of 1.5A. The converter features universal input and operates efficiently at 78%.
This model is designed for through-hole mounting and comes in a 9-DIP Module package with 5 leads. Its dimensions are 64.0mm in length, 45.6mm in width, and 23.5mm in height. The operating temperature range is -25°C to 70°C with derating.
The KMD15-55 complies with several standards, including 60601-1, 60950-1, and 62368-1, and has approval from agencies such as CE, EN, IEC, and UL. It is RoHS3 compliant and has a Moisture Sensitivity Level (MSL) of 1.
The KMD15-55 has a power rating of 15W.
The KMD15-55 provides a -5V output voltage.
The KMD15-55 has an output current of 1.5A.
The KMD15-55 features 2 outputs.
The KMD15-55 operates between -25°C and 70°C, with derating.
The KMD15-55 measures 64.0mm in length, 45.6mm in width, and 23.5mm in height.
The KMD15-55 complies with standards 60601-1, 60950-1, and 62368-1.
