KAS2107E The E-Switch KAS2107E is a Slide DIP Switch with SPST circuitry, featuring 7 positions and a 24VDC rating. It is designed for Through Hole mounting.
Mfr Part #:

KAS2107E

Available from 1 distributors
Mfr Name: E-Switch
E-Switch
The E-Switch KAS2107E is a Slide DIP Switch with SPST circuitry, featuring 7 positions and a 24VDC rating. It is designed for Through Hole mounting.
✓ Total Stock: 200 pcs
$ Price Range: $0.75

KAS2107E Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Husky International Electronic ✓
Non-Authorised Inventory information
200 pcs
On Request
200 pcs On Request 1 On Request On Request N/A On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

KAS2107E Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Actuator Level
Actuator Type
Circuit
Contact Finish
Contact Material
Current Rating (Amps)
Height Above Board
Lead Spacing
Mounting Type
Number of Positions
Operating Temperature
Pitch
Termination Style
Voltage Rating
Washable
View Similar Products (0)

KAS2107E Description

Short technical summary and product information.

The E-Switch KAS2107E is a reliable Slide DIP Switch designed for various electronic applications. This component features Single Pole Single Throw (SPST) circuitry and offers 7 distinct positions for versatile configuration.



With a current rating of 25mA at a voltage of 24VDC, the KAS2107E is suitable for low-power switching applications. The switch utilizes a Gold contact finish and Phosphor Bronze contact material, ensuring good conductivity and durability. Its pitch is 2.54mm (0.100"), and it has a height above the board of 9.90mm (0.390").



The mounting type is Through Hole with a Right Angle orientation, and the termination style is PC Pin, facilitating easy integration into circuit boards. The actuator type is a standard Slide, and the actuator level is Raised for ease of use. The operating temperature range is -40°C to 85°C, making it suitable for a wide range of environmental conditions.



This DIP switch is RoHS3 Compliant and has an MSL rating of 1 Unlimited. It is designed for applications requiring precise and reliable manual switching.

KAS2107E Quick Information

Product Type: DIP Switch
Canonical Name: E-Switch KAS2107E SPST DIP Switch
Subcategory: Slide DIP Switch

KAS2107E Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

KAS2107E Estimated Pricing

Qty Low High
1+ $0.75 $0.75

Estimated market price range - modelled values for guidance only, not live distributor offers.

KAS2107E Features

  • SPST circuit with 7 positions.
  • Rated for 25mA at 24VDC.
  • Through Hole, Right Angle mounting.
  • Gold contact finish for reliability.
  • Operates from -40°C to 85°C.

KAS2107E Applications

  • Ideal for board-level configuration.
  • Used in low-power switching circuits.
  • Suitable for manual setting applications.
  • Reliable for test point selection.

KAS2107E FAQs

5 frequently asked questions generated from this part’s specifications.
What is the operating voltage for the KAS2107E DIP Switch?

The operating voltage for the KAS2107E DIP Switch is 24VDC.

What is the operating temperature range of the KAS2107E?

The KAS2107E operates within a temperature range of -40°C to 85°C.

What type of mounting does the KAS2107E support?

The KAS2107E supports Through Hole, Right Angle mounting.

How many positions does the KAS2107E DIP Switch have?

The KAS2107E DIP Switch has 7 positions.

What is the current rating of the KAS2107E?

The current rating of the KAS2107E is 25mA.
