| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The MORNSUN K7815-500R3 is a high-efficiency switching regulator designed as a linear regulator replacement. It delivers a regulated 15V output at up to 500mA from a 19V to 36V input supply. With a typical efficiency of 95%, this module minimizes power loss and heat generation, making it suitable for space-constrained applications.
This converter is housed in a compact 3-SIP through-hole package measuring 11.6mm x 7.6mm x 10.2mm. It features short-circuit protection (SCP) and operates over a wide temperature range of -40°C to 85°C with derating. The module is approved by CB, CE, and cURus agencies for ITE (commercial) applications.
The K7815-500R3 is part of MORNSUN's K78 series, offering a drop-in replacement for traditional linear regulators with significantly improved efficiency. Its through-hole mounting and SIP footprint simplify integration into existing designs.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.09 | $1.09 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is 15V.
The maximum output current is 500mA.
The input voltage range is 19V to 36V.
The efficiency is 95%.
It comes in a 3-SIP through-hole module.
The operating temperature range is -40°C to 85°C with derating.
It is approved by CB, CE, and cURus.
