| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
8 pcs
|
8 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Material | |
| Contacts | |
| Country of Origin | |
| Current Rating | |
| Depth | |
| Failure Rate | |
| Length | |
| SVHC Present | |
| Terminal Type |
This Arcolectric (Bulgin) Ltd K22208EAAL is a DPDT slide switch designed for panel mounting. It offers an IP40 rating, making it suitable for applications where protection against solid objects is required.
The switch operates with a 250V AC contact voltage and has a current rating of 16A. It features tab terminals for easy connection and is constructed with a nylon actuator and case. The series designation is 2000.
This voltage selector slide switch is designed to select operating voltage in dual voltage equipment. It uses transformers with two independent windings that can be connected in parallel or series for 115V or 230V supplies. The switch has a red slider marked 115//230.
Approvals include ENEC, UL, and CSA, indicating compliance with relevant safety and performance standards. The switch has a depth of 12.8mm and a length of 33mm.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.00 | $1.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The K22208EAAL slide switch has a DPDT (Double Pole Double Throw) contact configuration.
This slide switch has a current rating of 16A.
The contact AC voltage rating for the K22208EAAL switch is 250V ac.
The K22208EAAL slide switch is designed for panel mounting.
The slide switch has an IP40 rating.
The actuator material is Nylon.
The approved standards for this slide switch include UL, RoHS, and CSA.
