| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
34,907 pcs
|
34907 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Control Features | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Lead Style | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Standard Number | |
| Storage Temperature | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Weight | |
| Width |
The XP Power JWL4024S15 is a high-performance isolated DC-DC converter from the JWL40 series, designed to deliver a regulated 15V output at 2.67A with a total power of 40W. It operates from a wide 4:1 input voltage range of 9 to 36V, making it suitable for applications with varying input sources. The converter achieves an efficiency of 89%, reducing thermal dissipation and improving system reliability.
This module provides 1500 VDC input-to-output isolation, ensuring safe operation in industrial and commercial ITE (Information Technology Equipment) environments. It includes features such as remote on/off control (enable, active high) and short circuit protection (SCP). The output voltage can be trimmed by ±10%, and the initial set accuracy is ±1.0%.
The JWL4024S15 is housed in a 6-DIP through-hole module measuring 50.8mm x 25.4mm x 10.2mm, with a six-sided metal case for improved EMI shielding and thermal performance. It operates over a wide temperature range of -40°C to +105°C, making it suitable for demanding environments.
| Qty | Low | High |
|---|---|---|
| 10+ | $86.66 | $86.66 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The JWL4024S15 provides a nominal output voltage of 15V with a maximum output current of 2.67A.
The input voltage range is 9V to 36V DC.
The operating temperature range is -40°C to +105°C.
It uses a 6-DIP through-hole module package.
The part is listed as RoHS3 compliant, but this is unverified.
The isolation voltage is a minimum of 1500 VDC.
Yes, it features remote on/off control with an enable, active high function.
