This Triad Magnetics JSU120-1500 is a versatile AC/DC converter designed for various applications. It operates with an input voltage rating of 100-240VAC and a frequency of 50-60Hz, providing a stable 12VDC output at 1.50A. The unit boasts an average efficiency of 85%, meeting Level VI efficiency standards.
Designed with a thermoplastic molded enclosure, this converter is suitable for rack mounting. It offers features such as universal input and protection against overvoltage and short circuits. The output is delivered via screw terminals for secure connections. The operating temperature range is 0°C to +40°C at full load, with a storage temperature range of -20°C to 60°C.
Safety and compliance are addressed with UL60950 and CSA C22.2 No. 60950-1 certifications, along with FCC Part 15 Class B EMI standards. It is also RoHS3 compliant. The dimensions are 74.9mm x 48.0mm x 31.0mm.
90-264VAC.
12VDC at 1.5A, 18W maximum.
0°C to +40°C at full load.
≥85% minimum, meets Level VI efficiency.
Thermoplastic molded enclosure with rack mount. Output via screw terminals.
5 years.
74.9mm (L) x 48.0mm (W) x 31.0mm (H).
