The XP Power JSK5024S24 is a 50W isolated DC-DC converter from the JSK50 series. It accepts an 18-36V DC input and provides a regulated 24V output at up to 2.08A. The converter features 1500VDC input-to-output isolation and operates over a wide temperature range of -40°C to +105°C, making it suitable for industrial and commercial (ITE) applications.
Key electrical characteristics include a typical efficiency of 91%, line and load regulation of ±0.5%, and an output ripple and noise of 150 mV pk-pk (with external capacitors). The module includes remote on/off control (active high enable), short circuit protection with hiccup mode auto recovery, and overvoltage protection at 30V. No minimum load is required for operation.
The JSK5024S24 is housed in a compact 6-DIP through-hole package measuring 50.8 x 25.4 x 11.0 mm (2.00 x 1.00 x 0.43 inches) and weighs 30 grams. It is designed for high power density and includes a six-sided metal case for improved EMI shielding. An optional heatsink is available (add suffix -HK).
| Qty | Low | High |
|---|---|---|
| 10+ | $92.48 | $92.48 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is 18-36V DC (2:1 ratio).
The output is 24V DC at up to 2.08A, providing 50W of power.
The operating temperature range is -40°C to +105°C.
It comes in a 6-DIP through-hole module measuring 50.8 x 25.4 x 11.0 mm.
The RoHS status is listed as RoHS3 compliant, but this is unverified.
Yes, it has continuous short circuit protection with hiccup mode and auto recovery.
The isolation voltage is 1500 VDC.
