| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
58 pcs
|
58 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Coil Voltage | |
| Contact Material | |
| Contact Resistance | |
| Insulation Resistance | |
| Operating Temperature | |
| Storage Temperature |
The JQX14FC from HF is an electromechanical relay featuring a 1 Form C (SPDT) contact configuration. It is designed for reliable switching in various industrial and automation applications.
This relay operates with a 12VDC coil voltage. The contact ratings include 10A at 250VAC for the 1C configuration, and 16A at 250VAC for the 1A configuration. It also supports motor load ratings of 1HP at 250VAC and 1/2HP at 125VAC, along with a TV-5 rating.
Key electrical specifications include a contact resistance of 100 MΩ (minimum at 500VDC) and dielectric strength of 1000V (50Hz) between coil and contacts, and 3000V (50Hz) for open contacts. The operating temperature range is -40°C to 70°C.
Mechanical dimensions are approximately 35.5mm x 21.5mm x 6.5mm. The pole distance options are 3.5mm and 5mm. Contact materials include AgSnO2 and AgCdO.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The JQX14FC relay has a coil voltage of 12VDC.
The JQX14FC relay features a 1 Form C (SPDT) contact configuration.
The 1C contact on the JQX14FC relay is rated for a maximum resistive load of 10A at 250VAC or 20A at 30VDC.
The JQX14FC relay can operate in temperatures ranging from -40°C to 70°C.
The JQX14FC relay has maximum dimensions of 35.5mm x 21.5mm x 6.5mm.
