| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
70 pcs
|
70 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Military Grade | |
| Operating Temperature | |
| SVHC Present | |
| Supplier Device Package |
The Microsemi JANTX1N2844B is a high-reliability Zener diode designed for demanding applications. It features a nominal Zener voltage of 160V and can dissipate up to 50W of power.
This diode is part of the Military, MIL-PRF-19500/114 series, indicating its suitability for stringent military and aerospace requirements. The component is housed in a TO-204AD (TO-3) package, which is known for its robust thermal performance and ease of mounting.
Key electrical characteristics include a maximum forward voltage of 1.5V at 10A and a reverse leakage current of 10µA at 121.6V. The Zener impedance is a maximum of 80 Ohms. The operating temperature range is from -65°C to 175°C, ensuring reliable operation across a wide spectrum of environmental conditions.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal Zener voltage (Vz) is 160V.
The maximum power dissipation is 50W.
The package type is TO-204AD (TO-3).
The operating temperature range is -65°C to 175°C.
The maximum forward voltage at 10A is 1.5V.
The reverse leakage current is 10µA at 121.6V.
The maximum Zener impedance (Zzt) is 80 Ohms.
