| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
200 pcs
|
200 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | |
| Lead Style | |
| Mounting Type | |
| Operating Temperature | |
| Power | |
| Supplier Device Package | |
| Transistor Type | |
| Vce Saturation (Max) @ Ib, Ic | |
| Voltage |
This NPN bipolar junction transistor from Microchip Technology, part number JANS2N3501UB, is suitable for various electronic applications requiring a surface mount component. It offers a collector-emitter breakdown voltage of 150V and can handle a continuous collector current of up to 300mA. The transistor has a maximum power dissipation of 500mW.
With a minimum DC current gain (hFE) of 100 at 150mA and 10V, and a Vce saturation of 400mV at 150mA collector current and 15mA base current, this device provides reliable performance. It is designed for operation within a temperature range of -65°C to 200°C. The JANS2N3501UB comes in a 4-SMD, No Lead (UB) package, making it ideal for space-constrained designs.
Its RoHS3 compliant status and MSL 1 rating indicate suitability for a wide range of manufacturing processes. The surface mount design simplifies integration into printed circuit boards.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
-65°C to 200°C (TJ)
300 mA
100 @ 150mA, 10V
4-SMD, No Lead
RoHS3 Compliant
