| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
15 pcs
|
15 pcs | On Request | 1 | On Request | On Request | 7649 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Diode Type | |
| Military Grade | |
| Mounting Type | |
| Power Dissipation | |
| SVHC Present |
The JAN1N5629A is a unidirectional Transient Voltage Suppressor (TVS) diode manufactured by QPL. This component is designed for voltage protection applications.
Key electrical specifications include a reverse standoff voltage of 5.8V, a minimum breakdown voltage of 6.45V, and a maximum clamping voltage of 10.5V at 10mA. It can handle a peak pulse current of 143A and has a peak pulse power dissipation rating of 1500W. The diode element is made of silicon.
This TVS diode operates within a temperature range of -65°C to 175°C. It is housed in a DO-13 package with axial leads, suitable for through-hole mounting. The component is also available in a bagged packaging option.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The reverse standoff voltage is 5.8V.
The peak pulse power dissipation is 1500W.
The JAN1N5629A is supplied in a DO-13 package.
The operating temperature range is -65°C to 175°C.
The JAN1N5629A is a unidirectional TVS diode.
