| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
831 pcs
|
831 pcs | On Request | 1 | On Request | On Request | 13+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Current | |
| Drain to Source Voltage (Vdss) | |
| Drive Voltage (Max Rds On, Min Rds On) | |
| FET Type | |
| Gate Charge (Qg) (Max) @ Vgs | |
| Industrial Grade | |
| Input Capacitance (Ciss) (Max) @ Vds | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Operating Temperature | |
| Power Dissipation (Max) | |
| Rds On (Max) @ Id, Vgs | |
| Supplier Device Package | |
| Tape & Reel | |
| Technology | |
| Vgs (Max) | |
| Vgs(th) (Max) @ Id |
This N-Channel MOSFET from IXYS, part number IXTP152N085T, is designed for power applications requiring high current handling. It offers a drain-to-source voltage (Vdss) of 85V and can sustain a continuous drain current (Id) of 152A at 25°C.
The MOSFET exhibits a low on-resistance (Rds On) of 7mOhm when measured at 25A and 10V gate drive voltage. The gate threshold voltage (Vgs(th)) is 4V at 250µA, and the maximum gate-source voltage (Vgs Max) is ±20V. Input capacitance (Ciss) is rated at 5500 pF at 25V, with a maximum gate charge (Qg) of 114 nC at 10V.
With a maximum power dissipation of 360W (Tc), this device is suitable for demanding applications. It operates within a wide temperature range of -55°C to 175°C (TJ). The component is housed in a TO-220-3 package and features through-hole mounting.
Compliance information indicates RoHS3 compliance, REACH unaffected status, and Moisture Sensitivity Level 1. The technology used is MOSFET (Metal Oxide).
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The drain-to-source voltage (Vdss) is 85 V.
The continuous drain current (Id) is 152A at 25°C.
The Rds On is a maximum of 7mOhm at 25A and 10V.
The operating temperature range is -55°C to 175°C (TJ).
The component is supplied in a TO-220-3 package.
It is designed for through-hole mounting.
The RoHS status is RoHS3 Compliant.
