The XP Power IW2412SA is a single-output isolated DC-DC converter designed for commercial ITE applications. It delivers a nominal 12V output at 83mA, providing 1W of isolated power from an 18V nominal input. The converter achieves a typical efficiency of 75% and includes short circuit protection (SCP) for reliable operation.
This module is housed in a compact 8-SIP package with 5 leads, measuring 21.9mm x 9.2mm x 11.1mm, and is designed for through-hole mounting. It operates over a wide temperature range of -40°C to 100°C with derating, making it suitable for various industrial environments.
The IW2412SA is safety certified to standard 62368-1 for ITE equipment. Its isolated module topology ensures input-to-output isolation, enhancing system safety and noise immunity in board-mount power supply designs.
| Qty | Low | High |
|---|---|---|
| 1+ | $9.69 | $9.69 |
| 5+ | $9.40 | $9.40 |
| 10+ | $9.11 | $9.11 |
| 20+ | $9.00 | $9.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is 12V nominal.
The output current is 83mA.
The power rating is 1W.
The nominal input voltage is 18V.
It comes in an 8-SIP Module with 5 leads, through-hole mounting.
The operating temperature range is -40°C to 100°C with derating.
The part is listed as RoHS3 Compliant, but this is unverified.
