| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3 pcs
|
3 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Lead Style | |
| Length | |
| Mounting Style | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Standard Number | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Width |
The XP Power IW2405SA is an isolated DC-DC converter module designed for commercial ITE applications. It provides a single regulated 5V output at 200mA, delivering 1W of output power. The converter operates from a nominal 18V input and achieves an efficiency of 72%.
This converter is housed in a compact 8-SIP package with 5 leads and through-hole mounting, measuring 21.9mm x 9.2mm x 11.1mm. It features short-circuit protection (SCP) and complies with safety standard 62368-1. The operating temperature range is -40°C to 100°C with derating.
Designed for board-mount power supplies, the IW2405SA is suitable for isolated power conversion in a variety of industrial and commercial equipment. Its isolated module architecture ensures input-to-output isolation, making it reliable for applications requiring galvanic isolation.
| Qty | Low | High |
|---|---|---|
| 1+ | $9.69 | $9.69 |
| 5+ | $9.40 | $9.40 |
| 10+ | $9.11 | $9.11 |
| 20+ | $9.00 | $9.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is 5V and the output current is 200mA, providing 1W of output power.
The nominal input voltage is 18V. Note: The part number suggests 24V input; the 18V value may be erroneous or represent the minimum input.
The efficiency is 72%.
It uses an 8-SIP module with 5 leads and through-hole mounting.
The operating temperature range is -40°C to 100°C with derating.
According to the data, it is RoHS3 compliant, but this value is unverified and should be confirmed from official documentation.
It complies with safety standard IEC 62368-1.
