IUGN6-1-59-20.0 The Sensata IUGN6-1-59-20.0 is a single-pole circuit breaker featuring a magnetic hydraulic delay mechanism. It is rated for 20A and 80V.
Mfr Part #:

IUGN6-1-59-20.0

Mfr Name: Sensata
Sensata
The Sensata IUGN6-1-59-20.0 is a single-pole circuit breaker featuring a magnetic hydraulic delay mechanism. It is rated for 20A and 80V.
Stock on Request

IUGN6-1-59-20.0 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Actuator Type
Approval Agency
Breaker Type
Current Rating
Current Rating (Amps)
Illumination
Mounting Type
Number of Poles
SVHC Present
Voltage Rating
View Similar Products (0)

IUGN6-1-59-20.0 Description

Short technical summary and product information.

This Sensata IUGN6-1-59-20.0 is a single-pole circuit breaker designed for panel mounting. It utilizes a magnetic hydraulic delay for its tripping mechanism, providing reliable overcurrent protection.



The breaker has a current rating of 20A and a voltage rating of 80V. It features a toggle actuator for manual operation and does not include illumination. The unit is approved by UL1077.



Environmental compliance includes RoHS3 compliance, MSL 1 rating, and REACH unaffected status. The part number for this component is IUGN6-1-59-20.0, with a distributor part number of 723-1360-ND.

IUGN6-1-59-20.0 Quick Information

Product Type: Circuit Breaker
Canonical Name: Sensata IUGN6-1-59-20.0 Magnetic Hydraulic Delay Circuit Breaker
Subcategory: Magnetic (Hydraulic Delay)

IUGN6-1-59-20.0 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

IUGN6-1-59-20.0 Features

  • 20A current rating for overcurrent protection.
  • 80V voltage rating for DC applications.
  • Magnetic hydraulic delay tripping mechanism.
  • Panel mount design with toggle actuator.
  • UL1077 approved for supplementary protection.

IUGN6-1-59-20.0 Applications

  • Used in control panel assemblies.
  • Suitable for supplementary circuit protection.
  • Ideal for DC power distribution.
  • Applications requiring 20A switching.

IUGN6-1-59-20.0 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the current rating of the IUGN6-1-59-20.0?

The current rating is 20A.

What is the voltage rating of this circuit breaker?

The voltage rating is 80V.

What type of breaker is the IUGN6-1-59-20.0?

It is a magnetic hydraulic delay circuit breaker.

How many poles does this circuit breaker have?

It has 1 pole.

What actuator type does this breaker use?

It uses a toggle actuator.

Is the IUGN6-1-59-20.0 UL approved?

Yes, it is UL1077 approved.

What is the mounting type for this circuit breaker?

It is panel mount.
