The Mean Well USA IRM-45-15ST is an open-frame AC/DC power supply designed for various applications. It delivers 45W of power with a single output voltage of 15V and a maximum output current of 3A.
This converter operates with a universal AC input range of 90-305VAC, making it suitable for global use. It boasts an efficiency of 88.5% and provides an isolation voltage of 3kV. The operating temperature range is -30°C to 70°C with derating.
With dimensions of 109.0mm x 52.0mm x 33.5mm, the IRM-45-15ST is designed for chassis mounting. It meets safety standards including UL60950-1 and TUV EN60950-1, and complies with EMC standards such as EN55022 Class B. Key features include universal input and suitability for ITE (Commercial) applications.
The IRM-45-15ST has an output voltage of 15V.
The maximum output current for the IRM-45-15ST is 3A.
The IRM-45-15ST has a power rating of 45W.
The IRM-45-15ST accepts a universal AC input voltage range of 90-305VAC.
The operating temperature range for the IRM-45-15ST is -30°C to 70°C, with derating.
The IRM-45-15ST is designed for chassis mounting.
The dimensions of the IRM-45-15ST are 109.0mm in length, 52.0mm in width, and 33.5mm in height.
