| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5 pcs
|
5 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Applications | |
| Approval Agency | |
| Automotive Grade | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Input Voltage | |
| Lead Spacing | |
| Lead Style | |
| Length | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Power (Watts) | |
| SVHC Present | |
| Storage Temperature | |
| Termination Style | |
| Type | |
| Voltage | |
| Width |
The Mean Well USA IRM-03-12S is a compact 3W AC/DC converter designed for board-mount applications. It offers a stable 12V output voltage and accepts a wide universal input voltage range of 85-305 VAC or 120-430 VDC.
This converter boasts an efficiency of 78% and features protections for short circuit, overload, and over voltage, ensuring reliable operation. Its design includes universal input and cooling by free air convection. The unit complies with EN55032 Class B EMI standards without additional components.
With dimensions of 37.0mm x 24.0mm x 16.0mm, the IRM-03-12S is suitable for space-constrained designs. It is built with Isolation Class II and comes with a 3-year warranty, making it a dependable choice for various power supply needs.
The module-type power supply is ready to be soldered onto the PCB, utilizing a Surface Mount (SMD) termination style. Its operating temperature range is -30°C to 85°C with derating.
The input voltage range is 85-305 VAC and 120-430 VDC.
The output voltage is 12V.
The power rating is 3W.
It includes protections for short circuit, overload, and over voltage.
The operating temperature range is -30°C to 85°C, with derating.
It is a 26-SMD Module with 14 Leads and uses Surface Mount.
Yes, it complies with EN55032 Class B without any additional components.
