The Mean Well USA IRM-02-15S is a compact AC/DC converter with a power rating of 2W and an output voltage of 15V. It offers a wide universal AC input voltage range from 85V to 305VAC, making it suitable for various global applications. This enclosed type converter is designed for surface mount (SMD) installation, with dimensions of 33.7mm x 22.2mm x 16.0mm.
Key features include overload and over-voltage protection, ensuring reliable operation. The unit operates efficiently with a typical efficiency of 75% and has a low no-load power consumption of less than 0.075W. It is cooled by free air convection and meets various safety and EMC standards, including UL60950-1, TUV EN60950-1, and EN55022 Class B.
With its robust design, isolation class II, and a 3-year warranty, the IRM-02-15S is a reliable choice for ITE (Commercial) applications requiring a compact and efficient power solution.
The input voltage range is 85 to 305 VAC (120 to 430 VDC).
The output voltage is 15V with a power rating of 2W (0.13A).
It includes short circuit protection, overload protection (hiccup mode, auto-recovery), and over voltage protection (115%-135% of rated output voltage).
The operating temperature range is -30°C to 85°C with derating.
It is available in a 24-SMD module (33.7 x 22.2 x 16.0 mm) for surface mount mounting.
It complies with UL60950-1, TUV EN60950-1, and design reference to IEC60601-1, EN60335-1, EN61558-1/-2-16. It has CB, CE, cURus, TUV approvals.
