Mfr Part #:

IRFR3710ZTRPBF

Mfr Name: Infineon

The Infineon IRFR3710ZTRPBF is an N-channel HEXFET Power MOSFET. It offers a 100V drain-source breakdown voltage and ultra-low on-resistance.

✓ Total Stock: 9,178 pcs

$ Price Range: $2.63

IRFR3710ZTRPBF Available from 5 distributors

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Fe Components ✓ Non-Authorised Inventory information	4,000 pcs On Request	4000 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
Optech Co.,Limited ✓ Non-Authorised Inventory information	3,020 pcs On Request	3020 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
Braun Electronic Components ✓ Non-Authorised Inventory information	1,000 pcs On Request	1000 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
Smaxon Electronics ✓ Non-Authorised Inventory information	793 pcs On Request	793 pcs	On Request	1	On Request	On Request	1752+	On Request	On Request
Bristol Electronics ✓ Non-Authorised Inventory information	365 pcs On Request	365 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

IRFR3710ZTRPBF Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	Infineon
Lead Spacing	2.54 mm
Mounting Type	Surface Mount
Storage Temperature	-55°C ~ 150°C
Tape & Reel	Tape and Reel

View Similar Products (0)

IRFR3710ZTRPBF Description

Short technical summary and product information.

The Infineon IRFR3710ZTRPBF is an N-channel HEXFET Power MOSFET designed for high efficiency and reliability. It features advanced process technology for extremely low on-resistance per silicon area, with a typical RDS(on) of 15mOhm at 10V VGS and 33A ID.

Key electrical specifications include a 100V drain-source breakdown voltage and a continuous drain current of 42A at 25°C (package limited). The device operates reliably up to a junction temperature of 175°C. It also supports repetitive avalanche energy up to Tjmax.

This MOSFET is supplied in a D-Pak surface-mount package. It is available on tape and reel, with a standard package quantity of 2000 units.

Applications benefit from its fast switching speed and improved repetitive avalanche rating, making it suitable for various power management tasks.

IRFR3710ZTRPBF Quick Information

Product Type: MOSFET

Series: IRFR3710Z

Canonical Name: Infineon IRFR3710ZTRPBF N-channel HEXFET Power MOSFET

Subcategory: N-Channel

IRFR3710ZTRPBF Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Lead Free: Lead-Free

IRFR3710ZTRPBF Estimated Pricing

Qty	Low	High
1+	$2.63	$2.63

Estimated market price range - modelled values for guidance only, not live distributor offers.

IRFR3710ZTRPBF Features

Ultra low on-resistance achieved.
175°C maximum operating temperature.
100V drain-source breakdown voltage.
42A maximum continuous drain current.
D-Pak surface mount package.

IRFR3710ZTRPBF Applications

Suitable for high-current power switching applications.
Ideal for motor control and inverter circuits.
Used in automotive and industrial power supplies.
Applicable in load switching for renewable energy systems.

IRFR3710ZTRPBF FAQs

7 frequently asked questions generated from this part’s specifications.

What is the maximum continuous drain current for the IRFR3710ZTRPBF?

The maximum continuous drain current is 42A at 25°C (package limited).

What is the drain-source breakdown voltage?

The drain-source breakdown voltage is a minimum of 100V.

What is the typical on-resistance (RDS(on))?

The typical on-resistance is 15mOhm at VGS = 10V and ID = 33A.

What is the maximum operating junction temperature?

The maximum operating junction temperature is 175°C.

What package type is the IRFR3710ZTRPBF supplied in?

It is supplied in a D-Pak package.

Is this component RoHS compliant?

The RoHS status is RoHS3 Compliant.

What is the Moisture Sensitivity Level (MSL)?

The Moisture Sensitivity Level is 1 Unlimited.
