| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,360 pcs
|
2360 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
295 pcs
|
295 pcs | On Request | 1 | On Request | On Request | 10+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Drain to Source Voltage (Vdss) | |
| Drive Voltage (Max Rds On, Min Rds On) | |
| FET Type | |
| Gate Charge (Qg) (Max) @ Vgs | |
| Input Capacitance (Ciss) (Max) @ Vds | |
| Lead Style | |
| Mounting Type | |
| Operating Temperature | |
| Power Dissipation (Max) | |
| Rds On (Max) @ Id, Vgs | |
| Supplier Device Package | |
| Tape & Reel | |
| Technology | |
| Vgs (Max) | |
| Vgs(th) (Max) @ Id |
The IRFR120NTRLPBF is an N-Channel enhancement mode power MOSFET manufactured by Infineon Technologies (formerly International Rectifier). It utilizes MOSFET (Metal Oxide) technology and is designed for high-efficiency power switching applications.
Key electrical specifications include a maximum drain-to-source voltage (Vdss) of 100 V and a continuous drain current (Id) of 9.4 A at case temperature (Tc). The maximum on-resistance (Rds(on)) is 210 mOhm, tested at Id = 5.6 A and Vgs = 10 V. The device features a maximum gate charge (Qg) of 25 nC at Vgs = 10 V and an input capacitance (Ciss) of 330 pF at Vds = 25 V. The threshold voltage (Vgs(th)) is a maximum of 4 V at Id = 250 µA. Maximum power dissipation is 48 W at Tc.
The device is supplied in a TO-252-3 (DPak, SC-63) surface-mount package (supplier package PG-TO252-3) and supports an operating junction temperature range of -55°C to +175°C. It is offered in a tape and reel format (as indicated by the TR suffix) and is specified as Lead-Free and RoHS3 Compliant (unverified per source notes).
The maximum drain-to-source voltage (Vdss) is 100 V.
The maximum continuous drain current is 9.4 A at case temperature (Tc).
The maximum on-resistance is 210 mOhm at Id = 5.6 A and Vgs = 10 V.
It is supplied in the TO-252-3 (DPak, SC-63) surface mount package, specifically the PG-TO252-3.
The operating junction temperature range is -55°C to +175°C.
The part is marked as RoHS3 Compliant and Lead-Free, but this compliance information is unverified according to source notes.
