| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
12,000 pcs
|
12000 pcs | On Request | 1 | On Request | On Request | 21+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Configuration | |
| Current | |
| Drain to Source Voltage (Vdss) | |
| FET Feature | |
| Gate Charge (Qg) (Max) @ Vgs | |
| Input Capacitance (Ciss) (Max) @ Vds | |
| Mounting Type | |
| Operating Temperature | |
| Power | |
| Rds On (Max) @ Id, Vgs | |
| Supplier Device Package | |
| Tape & Reel | |
| Technology | |
| Vgs(th) (Max) @ Id |
The IRF9952TRPBF is a dual N and P-Channel MOSFET from Infineon Technologies, designed for surface-mount applications. It features a maximum drain-source voltage of 30V for both channels, with drain current ratings of 3.5A for the N-channel and 2.3A for the P-channel. The device offers a maximum on-resistance of 100mOhm at 2.2A and 10V gate drive, and a gate threshold voltage of 1V at 250µA, making it suitable for logic-level gate drive applications. The MOSFET incorporates a logic-level gate feature for efficient switching.
The part is packaged in an 8-SOIC (0.154" width, 3.90mm width) with a surface-mount mounting type, and is available in the supplier device package 8-SO. It has a maximum power dissipation of 2W and an operating temperature range of -55°C to 150°C (junction). The input capacitance is 190pF at 15V drain-source voltage, and the gate charge is 14nC at 10V, indicating low switching losses.
This MOSFET array is suitable for various power management and switching applications, such as DC-DC converters, load switches, and battery management circuits, where both N and P-channel devices are required in a compact package.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.05 | $1.05 |
| 10+ | $0.65 | $0.65 |
| 100+ | $0.43 | $0.43 |
| 500+ | $0.33 | $0.33 |
| 1,000+ | $0.30 | $0.30 |
| 2,000+ | $0.27 | $0.27 |
| 4,000+ | $0.22 | $0.22 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum drain-source voltage is 30V.
It is available in an 8-SOIC (0.154", 3.90mm Width) surface-mount package.
The operating junction temperature range is -55°C to 150°C.
Yes, it is marked as RoHS3 compliant, though unverified.
The N-channel can handle 3.5A maximum, and the P-channel 2.3A maximum.
Yes, it has a logic-level gate feature with a threshold voltage of 1V at 250µA.
